How is manganese silicide MnSi2 powder produced?

Put 2g (0.036mol) manganese, 2g (0.071mol) silicon and 10g (0.16mol) copper in small pieces into a 10ml Al2O3 crucible in a quartz ampoule with an open end. After being emptied and melted, the ampoule is placed in a high-temperature furnace with carbon silicon rods. Raise the temperature to 1200°C within 12 hours, then decrease the temperature to 500°C at 10°C/ChemicalBookH. Take out the ampoule, cool it, then insert it into a large diameter rubber tube and break the ampoule so that the ingot can be safely removed. The copper-rich Cu-Mn-Si substrate was dissolved in 8mol/L nitric acid, leaving octahedral crystals. The crystals were washed with water and dried to obtain MnSi2 crystals with a side length of 2 mm.

Overview of manganese silicide MnSi2 powder

Manganese silicide MnSi2 powder (CAS 12032-86-9) has the dual characteristics of high melting point, high corrosion resistance, high oxidation resistance, good electrical conductivity, high temperature ductility, intermediate phase binary alloy system, metal and ceramics .Manganese silicide MnSi2 is an intermetallic compound, which is a silicide of manganese. Manganese silicide is a transition metal silicide, a refractory intermetallic compound. Manganese disilicide (MnSi2) nanomaterials have special electrical, optical, magnetic and thermoelectric properties, and even have potential application value in the field of catalysis. It is a non-stoichiometric compound, and silicon defects are expressed as MnSi2-x. The crystal structure of many MnSi2-x compounds is similar to that of a chimney ladder and is called the Nowotny phase.

Application of manganese silicide MnSi2 powder

Due to its unique physical and chemical properties, manganese disilicide (MnSi2)has been successfully applied to materials and photovoltaic materials in the fields of complementary metal oxide semiconductor components, thin film coatings, body structure components, electric heating components, thermoelectrics, etc.

By using manganese silicate thermoelectric conversion material, the power factor of the power generation capacity is 2.4mW/K2m, which is about twice the original power. Engines, industrial furnaces and other industrial furnaces are also expected to convert 300-700°C waste heat and other waste heat into electrical energy for use in high-power thermoelectric power generation modules.

Manganese silicide MnSi2 powder price

The price of manganese silicide MnSi2 powder will vary randomly with factors such as production cost, transportation cost, international situation, exchange rate, market supply and demand of manganese silicide MnSi2 powder. Tanki New Materials Co., Ltd. aims to help various industries and chemical wholesalers find high-quality, low-cost nanomaterials and chemicals by providing a full set of customized services. If you are looking for manganese silicide MnSi2 powder, please feel free to send an inquiry to get the latest price of manganese silicide MnSi2 powder.

Manganese silicide MnSi2 powder supplier

As a global manganese silicide MnSi2 powder supplier, Tanki New Materials Co., Ltd. has extensive experience in the performance, application and cost-effective manufacturing of advanced and engineered materials. The company has successfully developed a series of powder materials (molybdenum disilicide, titanium silicide, calcium silicide, iron boride), high-purity targets, functional ceramics and structural devices, and provides OEM services.
