What is the scope of application of WSi2 powder?

Overview of tungsten silicide WSi2 powder

Silicides are used as contact materials in microelectronics and have a resistivity of 60-80 μΩcm. It forms 1000°C. It is often used as a shunt for polysilicon wires to increase their conductivity and increase signal speed. The silicide layer can be prepared by chemical vapor deposition, for example, using monosilane or dichlorosilane and tungsten hexafluoride as source gases. The deposited films are non-stoichiometric and require annealing to convert to a more final stoichiometric form. Tungsten silicide can replace earlier tungsten films. Tungsten silicide can also be used in MEMS and anti-oxidation coatings.

Tungsten silicide is insoluble in water and aqua regia, but soluble in nitric acid and hydrofluoric acid mixture. For the system of anti-oxidation coating and resistance wire dressing.

Preparation method of tungsten silicide

(1) Mix tungsten powder and silicon powder in a molar ratio of 1:2, and mix titanium powder and graphite powder in a molar ratio of 1:1, and then mix them evenly.

(2) The W-Si mixed powder is placed in the center of the crucible, and the Ti-C mixed powder is evenly placed between the W-Si mixed powder and the crucible. Finally, a layer of Ti-C mixed powder is placed on top of all the mixed powders. The weight ratio of the loaded Ti-C mixed powder and W-Si mixed powder is (0.8~1.2): 1

(3) Put the crucible containing the mixed powder into a closed reactor, evacuate and fill with argon, and then energize the mixture with a tungsten wire to initiate the reaction between the mixed materials.

(4) Take out the reacted material after cooling, separate titanium carbide and tungsten disilicide, and crush them to obtain titanium carbide and tungsten disilicide powder.

Application of tungsten silicide WSi2 powder

Tungsten silicide WSi2 powder is used in microelectronics as electrical shock material, shunting on polysilicon wires, anti-oxidation coatings and resistance wire coatings. Tungsten silicide is used as a contact material in microelectronics with a resistivity of 60-80 μΩcm. It forms at 1000°C. It is often used as a shunt for polysilicon wires to increase their conductivity and increase signal speed. The tungsten silicide layer can be prepared by chemical vapor deposition, such as vapor deposition. Monosilane or dichlorosilane and tungsten hexafluoride are used as raw material gases. The deposited films are non-stoichiometric and require annealing to convert to a more conductive stoichiometric form.

Tungsten silicide can replace earlier tungsten films. Tungsten silicide also acts as a barrier between silicon and other metals.

Tungsten silicide is also valuable in microelectromechanical systems, where tungsten silicide is primarily used as a thin film for making microcircuits. For this purpose, the tungsten silicide film may be plasma etched using, for example, silicide.

Tungsten silicide WSi2 powder price

The price of tungsten silicide WSi2 powder will vary randomly with the production cost of tungsten silicide WSi2 powder, transportation cost, international situation of tungsten silicide WSi2 powder, exchange rate and market supply and demand of tungsten silicide WSi2 powder. Tanki New Materials Co., Ltd. aims to help industries and chemical wholesalers find high-quality, low-cost nanomaterials and chemicals by providing a full range of customized services. If you are looking for tungsten silicide WSi2 powder, please feel free to send an inquiry to get the latest price of tungsten silicide WSi2 powder.

Tungsten Silicide WSi2 Powder Supplier

As a global tungsten silicide WSi2 powder supplier, Tanki New Materials Ltd. has extensive experience in the performance, application and cost-effective manufacturing of advanced and engineered materials. The company has successfully developed a series of powder materials (molybdenum disilicide, titanium silicide, calcium silicide, iron boride), high-purity target materials, functional ceramics and structural devices, and provides OEM services.
